PW812810 turbo oil return hose for Proton 1.6T CFE cars. Heat & oil resistant, direct OEM replacement to fix turbo oil leaks for repair, refurbishment and turbo overhaul.
OE NUMBER: PW812810
APPLICATION CAR: Proton
SIZE: STANDARD
WARRANTY:1 year
ACCEPTED OEM SERVICE:YES
MOQ:100pcs
PACKAGE:Plastic bag+ Carton + Pallet or According to our customer's request
LOGO:Laser marking our customer's LOGO on the products
DELIVERY TIME:30 DAYS, If new model, it will be 45 days.
Item NO.:
PW812810Order(MOQ):
100Payment:
TT, LC, PAYPALProduct Origin:
CHINAColor:
OEM STANDARDShipping Port:
SHANGHAI OR NINGBOLead Time：
30 DAYSProduct Description
Product Name: PW812810 Turbocharger Oil Pipe for Proton 2012-2023
PW812810 is an OE-standard turbocharger oil return pipe specially developed for Proton 1.6L CFE turbo engine models. Manufactured with multi-layer reinforced rubber and precision steel joints, this pipe features high temperature resistance, oil corrosion resistance and stable pressure resistance. It fully complies with original factory dimensional specifications, supporting direct plug-and-play replacement without any modification. As a core vulnerable aftermarket part, it effectively solves common faults such as oil leakage, poor turbo oil return and turbo overheating caused by aging of original pipes, and ensures the normal lubrication and heat dissipation of turbocharger bearings.
Product Specification Table
| Item | Details |
|---|---|
| OE Part Number | PW812810 |
| Product Name | Turbocharger Oil Return Pipe / Turbo Oil Cooling Hose |
| Vehicle Make | Proton (Malaysian mainstream automotive manufacturer) |
| Compatible Vehicle Models | Proton Preve CFE Turbo, Proton Exora Bold Turbo, Proton Suprima S 1.6T CFE |
| Applicable Model Year Range | 2012 - 2023 |
| Engine Model | 1.6L CamPro CFE Turbo (Charged Fuel Efficiency) |
| Engine Displacement | 1561 cc (Bore × Stroke: 76mm × 86mm) |
| Engine Power Output | 103 kW / 138 HP / 140 PS @ 5000 rpm |
| Engine Torque Output | 205 N·m @ 2000-4000 rpm |
| Matched Turbocharger Model | KP39 |
| Installation Position | Turbocharger oil return circuit (oil cooling return line, between turbocharger assembly and engine oil pan) |
| Overall Pipe Length | 280 mm (OE standard dimension) |
| Material Construction | Multi-layer reinforced structure: inner oil-resistant nitrile rubber (NBR) layer, high-strength fiber braided reinforcement layer, outer heat-resistant EPDM rubber layer, with precision-formed steel mounting joints |
| Operating Temperature Range | -40°C to +180°C |
| Rated Working Pressure | Up to 1.2 MPa |
| Replacement OE Numbers | PW812814, PW913366 |
| Core Function | Turbocharger oil return, oil cooling and diversion, ensures continuous lubrication and cooling of turbocharger bearings |
| Key Aftermarket Features | OE-spec direct fit, no modification required, leak-proof design, high temperature & oil corrosion resistance, factory pressure & aging tested |
| Application Scenarios | Professional aftermarket replacement for auto repair shops, cross-border auto parts retail, used car maintenance, turbo overhaul kit matching |
| Warranty | 12 months / 20,000 km (whichever comes first) |
Application Scenarios Corner
Product Showcase
Why Partner With Us?
A: Each step of our production process have the quality checking workers. They will check the products one by one before going to next production step. And before package, our QC workers will choose 15% of the cargo to check the quality again to make sure the cargo is with good quality. If the 15% products have around 1% with defects, we will recheck all pieces of the cargo. And our quality warranty is 2 years. If any quality issues feedback from our customers, we will fully take charge of it.
2. Q: How long is your delivery term?
A: Our standard product delivery term is normally 30 days.A new product development is 60days including the mass production. Under normal circumstances there are standing stock for regular types.You can email us to learn more details.
3. Q: How many years is your company in auto parts business field?
A: Our Company started since 2005,there is about 19 years history forus in auto parts business field.
4. Q:Are you trading company or factory?
A: We are factory with trading company.
5. Q:What's the MOQ for each item?
A: Our business way is spot sales,if the items we have stock,there is no limitation for MOQ to be manufactured based on your order.
Product FAQs:
1. Q: Can you produce hoses based on drawings?
A: Absolutely. We support custom production according to technical drawings, 3D models, or physical samples.
2. Q: Are your turbo hoses suitable for diesel engines?
A: Yes. Our products are widely used in both gasoline and diesel turbocharged engines.
